DESCRIPTION

Basic Info.

Type	Floating Ball Valve
Function	Blow-Down Valve
Temperature	Normal Temperature
Application	Industrial Usage, Water Industrial Usage, Household Usage
Certificate 1	Dnv CE 0575
Inspect & Test	API 598
Certificate 3	API 600
Certificate 4	API 6D
Certificate 2	ISO 9001: 2008
Pre-Temp. Rating	ASME B16.34
Ends Connection	RF, NPT, Bw, Sw
Face to Face	ASME B16.10
Design & Manufacture	API 6D, ASME B16.34 & BS5351
Characteristic	Ball Valve
Transport Package	Standard Sea Worthy
Specification	API 6D
Trademark	VATAC/OEM
Origin	China
HS Code	84818040
Production Capacity	8000ton Per Year

Product Description

Carbon or Stainless Steel Forged Ball Valve Conform to API 6D, BS5351, and ASME B16.34.
They are tested according to API 598, and marked as per MSS SP-25
1. Construction is as follows:

- Full Port or Reduce Port

- One Piece or Split Body

- Bolted Bonnet with spiral-would gasket

- Fire Safe Design

- Anti-static Design & Blow-out proof stem

- Socket Weld Ends to ASME B16.11

- Butt Weld Ends to ASME B16.25

- Screwed Ends to ANSI/ASME B1.20.1

- Flanged Ends to ASME B16.5

2. Main Part & Materials

Part Names	Part Materials
Body	WCB/A105	LCB/LF2	WC6/F22	CF8/F304	CF8M/F316	CF3/F304L	CF3M/F316L
Bonnet	WCB/A105	LCB/LF2	WC6/F22	CF8/F304	CF8M/F316	CF3/F304L	CF3M/F316L
Ball	A105+ENP	SS304	F22	SS304	SS316	SS304L	SS316L
Stem	A105	F304	F6a	F304	F316	F304L	F316L
Seat/Seat Ring	PTFE/RPTFE/NYLON/DEVLON/PEEK or METAL
Packing	Graphite/PTFE
Gasket	SS304+Graphite/SS316+Graphite
Bolts/Nuts	B7/2H	L7/4	B16/4	B8/8	B8M/8M	B8/8	B8M/8M
Suitable Medium	W.O.G etc.			HNO3, CH3OOH etc.
Suitable Temperature	-29~425 °C	-46~340 °C	-46~340 °C	-196~427 °C	-196~427 °C	-196~427 °C	-196~427 °C

3. Normal Pressure Rating
PN10~PN420, CLASS150~2500
4. Normal Size Range
DN15~DN100, 1/2"~4"
