DESCRIPTION

Basic Info.

Model NO.	FSV-014
Actuator	Manual
Seal Surface	Wedge Gate Valve
Thread Position of Valve Rod	Inside Gate Valve
Usage	Regulation, Drain, Flow Control
Standard	DIN
Application	Industrial Usage, Water Industrial Usage, Household Usage
Wedge	Ductile Iron (GGG50)
Stem	Stainless Steel 304
O Ring	NBR/EPDM
Gland	Stainless Steel 304
Thrust Washer	PTFE/Nylon
Wedge Nut	Brass
Hand Wheel	Ductile Iron (GGG50)
Pressure Rate	PN10/16
Body	Ductile Iron (GGG50)
Operator	Cap Nut/Handwheel
Bolts	Carbon Steel/Stainless Steel
Bonnet	Ductile Iron (GGG50)
Design Stanard	BS5163,DIN3352,AWWA ,C509/515 or Custom Made
Transport Package	Wooden Case
Specification	DN50-600
Trademark	WALTER, OEM
Origin	Suzhou
HS Code	8481801090
Production Capacity	800 Sets Per Month

Product Description

DIN F4 Ductile Iron Resilient Seat Gate Valve
Application:
Resilient Seat Gate Valve are suitable for use in potable water,sewage water,water supply,fire-ffighting system.
As a experienced valve manufacturer,we keep high quality Resilient Seat Gate Valve with 0-LEAKAGE!

Item	Part	Material
1	Body	EN GJS 500-7
2	Bonnet	EN GJS 500-7
3	Bonnet Screw	C.S
4	Nuts	SS304
5	Bonnet	Ductile Iron(GGG50)
6	Wedge	DI+EPDM
7	Wedge Nut	Brass
8	Stem	AISI 420
9	Stem Nut	Brass
10	Seal Rings	NBR/EPDM
11	Hand Wheel	DI(Cap is Optional)

Code No.	Size	DN	L(F4)	L(BS)	D1	D2	D3	H	n-zφd PN10	n-zφd PN16
NRGV-0050	2"	50	150	178	99	125	165	220	4-φ19	4-φ19
NRGV-0065	21/2"	65	170	190	118	145	185	240	4-φ19	4-φ19
NRGV-0080	3"	80	180	203	132	160	200	290	8-φ19	8-φ19
NRGV-0100	4"	100	190	229	156	180	220	330	8-φ19	8-φ19
NRGV-0125	5"	125	200	254	184	210	250	375	8-φ19	8-φ19
NRGV-0150	6"	150	210	267	211	240	285	420	8-φ23	8-φ23
NRGV-0200	8"	200	230	292	266	295	340	500	8-φ23	12-φ23
NRGV-0250	10"	250	250	330	319	355	405	610	12-φ23	12-φ28
NRGV-0300	12"	300	270	356	370	410	460	720	12-φ23	12-φ28
NRGV-0350	14"	350	290	381	429	470	520	920	16-φ23	16-φ28
NRGV-0400	16"	400	310	406	480	525	580	940	16-φ26	16-φ31
NRGV-0450	18"	450	330	432	548	585	640	1150	20-φ26	20-φ31
NRGV-0500	20"	500	350	457	609	650	705	1350	20-φ26	20-φ34
NRGV-0600	24"	600	390	508	720	770	840	1500	20-φ30	20-φ37

Suzhou Walter Flow Control Equipment Co., Ltd. Can supply OEM for suice valve, gate valve, flange butterfly valve, check valve, strainer, pressure reducing valve, fire hydrant etc.
MORE TRUST,MORE COOPRATION.
WE ALWAYS WELCOME YOUR INQUIRY AND VISITING!
